Ultra-high efficiency ECO Series UPS System saves energy by automatically powering off unused computer accessories when the computer is not in use. UPS system uses less electricity than conventional models. Design includes four battery-supported outlets for computer, monitor and two vital system peripherals, plus four additional surge suppression-only outlets for accessories not requiring battery support. Three of the surge-only outlets are designated Eco outlets that can be configured to automatically power off when the computer enters standby mode or is shutdown. USB port enables UPS configuration options and unattended system shutdown without data loss in the case of extended power failure. UPS system meets RoHS standards. 550VA/300-watt power handling ability supports entry-level PC systems for up to 17 minutes during power fail conditions.
| Dimensions / Specifications | |
|---|---|
| Unit of Measure | EA |
| Item Dimensions | 8.00 in. x 4.30 in. x 13.30 in. (W x H x D) |
| Item Weight | 7.100 lbs |
| Box Pack Quantity | 1 EA |
| Carton Pack Quantity | 4 EA |
| Carton Pack Dimensions | 15.51 in. x 11.26 in. x 23.30 in. (W x H x D) |
| Carton Pack Weight | 36.800 lbs |
| This item is sold by the EA | |
| Shipping Info | |
|---|---|
| Can Ship via UPS? | Yes |
| Can Ship via Air Carrier? | Yes |
| Hazmat restrictions? | No |
| Additional Information | |
|---|---|
| Has Energy Star Rating? | Yes |
| Considered Green (less environmental impact)? | Yes |
| Made of Some or All Recycled Materials? | No |
| Warranty Offered? | Yes |
| Warranty Comments | Manufacturer's limited three-year warranty. |
| Underwriter's Laboratory Listed? | Yes |
| Item Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | ECO550UPS |
| Product Series | ECO |
| Product Model | ECO550UPS |
| Product Name | ECO550UPS 550VA Ultra-compact Desktop/Tower/Wall Mount UPS |
| Packaged Quantity | 1 Each |
| Product Type | Standby UPS |
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 10 x NEMA 5-15R |
| Number of Surge-only Outlets | 5 |
| Dataline Protection | RJ-11 |
| Protection Type | EMI / RFI |
| Protection Type | Brownout |
| Protection Type | Power Failure |
| Overload Protection | Yes |
| Cord Length | 6 ft |
| Transfer Time | 6 ms |
| Phase | Single Phase |
| Application/Usage | Retail |
| Application/Usage | Hospital |
| Application/Usage | Computer Peripheral |
| Load Capacity (VA) | 550 VA |
| Load Capacity (Watt) | 300 W |
| Input Voltage | 120 V AC |
| Output Voltage | 110 V AC |
| Output Voltage | 115 V AC |
| Output Voltage | 120 V AC |
| Output Frequency | 60 Hz |
| Waveform Type | Pure Sine Wave |
| Surge Energy Rating | 316 J |
| Alarm | Battery Fault |
| Alarm | Overload |
| Alarm | Low Battery |
| Status Indicators | 2 LED Indicator: Line power, Battery power statusMain Power Switch Controls : ON, OFF, SELF-TEST, ALARM CANCEL, Second switch enables "ECO" outlet switching |
| USB | Yes |
| USB (HID Compliant) Port | Yes |
| DC System Voltage | 12 V DC |
| Battery Characteristics | Valve-regulated |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 1.20 Minute |
| Backup/Run Time (Half Load) | 5 Minute |
| Battery Life | 6 Year |
| Typical Battery Recharge Time | 6.50 Hour |
| Replaceable Battery | Yes |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Storage Temperature | 5°F (-15°C) - 133°F (56.1°C) |
| Maximum Storage Elevation | 6561 ft |
| Sound Emission | 40 dB |
| Thermal Dissipation | 1.17 W |
| Color Family | Black |
| Product Color | Black |
| Height | 4.13" |
| Width | 4.33" |
| Depth | 7.28" |
| Form Factor | Ultra-compact Desktop/Tower/Wall Mount |
| Weight (Approximate) | 5.20 lb |
| Package Contents | ECO550UPS 550VA Ultra-compact Desktop/Tower/Wall Mount UPS, USB Cable, Owner's Manual |
| Additional Information | Keyhole mounting slots enable wall-mount installation, Compatible with Tripp Lite's Watchdog system service to restore operation to locked equipment through soft reboot of application / OS or hard power off/on reboot of connected equipment - ideal for unattended kiosk applications, Switches to battery power as line voltage decreases to 99 volts or less. Resets back to line power mode as line voltage increases to 104V or higher, Switches to battery power as line voltage increases to 139V or higher. Resets back to line power mode when line voltage decerases to 135V or lower, Basic desktop PCs for home/home-office use, network terminals, audio/video and home entertainment systems and other sensitive electronic devices, 550VA / 300 watt UPS provides battery-derived AC output during brownouts and power failures to support entry-level desktop computer with 15 inch LCD monitor up to 17 minutes |
| Certifications & Standards | Tested to : UL1778 (USA), CSA (Canada), NOM (Mexico), Class B (EMI), FCC Part 68 / Industry Canada (telecommunication) |
| Software Included | PowerAlert software available via free download |
| Recycled | No |
| Assembly Required | No |
| Energy Star | Yes |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Energy Efficiency Certification | ENERGY STAR 2.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 2 year $100,000 connected equipment guarantee |
| Manufacturer Info | |
|---|---|
| Brand | Tripp Lite by Eaton |
| Warranty Offered? | Yes |
| Manufacturer SKU | ECO550UPS |
| Retail GTIN (UPC) | 00037332211064 |
| Country of Origin | CN |
| UNSPSC Number | 39121011 |
| Product ID | 9288127 |
