Premium protection for essential network workstations, telecom systems, point-of-sale equipment and audio/video systems, the ISOBAR8ULTRA Isobar® 8-Outlet Surge Protector features a network-grade surge protection rating of 3840 joules to defend your sensitive electronics against even the strongest surges and spikes.Because residential power outlets have three wires-hot line (H), neutral (N) and ground (G)-the ISOBAR8ULTRA protects all three, covering the two protection modes: full normal mode (H-N) and common mode (N-G/H-G).Your devices plug into eight widely spaced NEMA 5-15R outlets, which are arranged in four exclusive isolated filter banks. These internal barriers filter out electromagnetic interference (EMI) and radio frequency interference (RFI) that can disrupt your electronics and inflict hardware damage or data loss.Included safety covers block accidental contact with unused outlets. An integrated 12A circuit breaker protects all outlets and shuts down connected equipment in case of overload. The lighted on/off switch provides one-touch control over connected equipment. Diagnostic LEDs confirm power, protection and line fault status. The 12-foot (3.7-meter) AC power cord includes a space-saving right-angle NEMA 5-15P plug.
| Dimensions / Specifications | |
|---|---|
| Unit of Measure | EA |
| Item Dimensions | 12.64 in. x 3.10 in. x 21.85 in. (W x H x D) |
| Item Weight | 3.720 lbs |
| Carton Pack Quantity | 12 EA |
| Carton Pack Dimensions | 12.64 in. x 12.52 in. x 21.85 in. (W x H x D) |
| Carton Pack Weight | 47.430 lbs |
| This item is sold by the EA | |
| Shipping Info | |
|---|---|
| Can Ship via UPS? | Yes |
| Can Ship via Air Carrier? | Yes |
| Hazmat restrictions? | No |
| Additional Information | |
|---|---|
| Considered Green (less environmental impact)? | No |
| Made of Some or All Recycled Materials? | No |
| Warranty Offered? | Yes |
| Warranty Comments | Manufacturer's limited lifetime warranty. |
| Item Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | ISOBAR8 ULTRA |
| Product Line | Isobar |
| Product Model | ISOBAR8ULTRA |
| Product Name | 8-outlet Premium Surge Suppressor |
| Packaged Quantity | 1 Each |
| Product Type | Surge Suppressor/Protector |
| Plug/Connector Type | NEMA 5-15P |
| Receptacles | 8 x NEMA 5-15R |
| Features | LED Indicator |
| Features | Auto Shut-off |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Maximum Line Current | 15 A |
| Maximum Surge Current | 61 kA |
| Power Handling | 1440 VA |
| Surge Energy Rating | 3840 J |
| Circuit Breaker | Yes |
| Status Indicators | Protection Present, Line Fault, Line OK |
| Color Family | Gray |
| Product Color | Light Gray |
| Product Material | Metal |
| Power Cord/Cable Length | 12 ft |
| Height | 2.5" |
| Width | 9" |
| Depth | 3.5" |
| Weight (Approximate) | 3.30 lb |
| Package Contents | 8-outlet Premium Surge Suppressor, 4 x Outlet safety covers, Owner's manual |
| Additional Information | Multi-component suppression circuits combine torroidal chokes, ferrite rod-core inductors, HF/VHF capacitors and multiple layers of metal oxide varistors into exclusive isolated filter banks that remove EMI/RFI interference, even noise from other pieces of connected equipment, Widely spaced outlets accommodate up to 4 large transformer plugs without blocking outlets, Keyhole mounting tabs allow permanent installation |
| Compatibility | Ideal for premium protection of personal computers with peripherals, network and CAD/CAM/CAE workstations, internetworking accessories, telecommunications systems, point of sale equipment, audio/video and home theater systems in any home, office or industrial application |
| Certifications & Standards | IEEE 587 category A and B, ANSI C62.41, UL1449 (Let through rating 330V), UL1283, UL1363, cUL |
| Recycled | No |
| Post-consumer-waste% | 0% |
| Assembly Required | No |
| Country of Origin | Philippines |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Limited Warranty | Lifetime |
| Directly Connected Equipment Guarantee | $50000 |
| Manufacturer Info | |
|---|---|
| Brand | Tripp Lite by Eaton |
| Warranty Offered? | Yes |
| Manufacturer SKU | ISOBAR8 ULTRA |
| Retail GTIN (UPC) | 00037332010551 |
| Country of Origin | PH |
| UNSPSC Number | 39121610 |
| Product ID | 5630454 |
