Line-Interactive Digital UPS System offers voltage regulation, surge suppression and battery support for personal computers, network workstations and more. Internal UPS circuits support entry-level PCs for 60 minutes or individual VCR/DVR for 3 hours during power failure. AVR circuits regulate brownouts as low as 89 volts back to usable levels without using battery power. Includes 4 battery-supported outlets, plus 4 surge suppression-only outlets. USB port enables optional unattended system shutdown without data loss; cable included. HID-compliant USB interface enables integration with built-in power management and auto shutdown of Windows, Mac OS X and Linux. Built-in single-line RJ-11 phone suppression jacks protect modem and satellite receiver with standard dialup/DSL phone connection. 2.2 GHz coaxial jacks protect against surges on CATV, satellite or broadcast antenna connections. 3 minute battery runtime with full load of 1000VA/500W and 10 minutes with half load of 500VA/250W.
| Dimensions / Specifications | |
|---|---|
| Unit of Measure | EA |
| Item Dimensions | 10.40 in. x 4.75 in. x 15.60 in. (W x H x D) |
| Item Weight | 15.600 lbs |
| Box Pack Quantity | 1 EA |
| Box Pack Dimensions | 9.60 in. x 5.10 in. x 14.50 in. (W x H x D) |
| Box Pack Weight | 15.300 lbs |
| Carton Pack Quantity | 2 EA |
| Carton Pack Dimensions | 13.00 in. x 11.00 in. x 15.75 in. (W x H x D) |
| Carton Pack Weight | 32.200 lbs |
| This item is sold by the EA | |
| Shipping Info | |
|---|---|
| Can Ship via UPS? | Yes |
| Can Ship via Air Carrier? | Yes |
| Hazmat restrictions? | No |
| Additional Information | |
|---|---|
| Considered Green (less environmental impact)? | No |
| Made of Some or All Recycled Materials? | No |
| Warranty Offered? | Yes |
| Warranty Comments | Manufacturer's limited three-year warranty. |
| Underwriter's Laboratory Listed? | Yes |
| Item Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | SMART1000LCD |
| Product Line | SmartPro |
| Product Name | SmartPro 1000 VA Tower Digital UPS |
| Packaged Quantity | 1 Each |
| Product Type | Line-interactive UPS |
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 4 x NEMA 5-15R |
| Dataline Protection | RJ-11 |
| Transfer Time | 4 ms |
| Load Capacity (VA) | 1000 VA |
| Load Capacity (Watt) | 500 W |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Surge Energy Rating | 1038 J |
| USB | Yes |
| Backup/Run Time (Full Load) | 3 Minute |
| Backup/Run Time (Half Load) | 10 Minute |
| Battery Life | 6 Year |
| Typical Battery Recharge Time | 8 Hour |
| Maximum Operating Temperature | 122°F (50°C) |
| Color Family | Black |
| Product Color | Black |
| Height | 10.43" |
| Width | 15.55" |
| Depth | 4.84" |
| Rack Height | 2U |
| Form Factor | Tower |
| Weight (Approximate) | 14.60 lb |
| Package Contents | SmartPro 1000 VA Tower Digital UPS, SMART1000LCD Digital UPS, USB and phone cabling, Manual with warranty information |
| Additional Information | Low voltage transfer to battery power: Switches to battery power as line voltage decreases to 89V or less, switches back to AC mode as line voltage increases to 94V or higher, High voltage transfer to battery power: Switches to battery mode as line voltage increases to 139V or higher, switches back to AC mode as line voltage decreases to 135V or lower, Typical Applications: Entry-level PCs, networked workstations, point-of-sale equipment, small business phone systems, audio/video equipment and home theater systems. Ideal for sensitive electronic applications in areas where brownout conditions are common, Cold Start: Yes, inverter can be "cold started" to enable temporary AC output during a power failure, Switches: Includes 2 front panel switches - one main on/off power switch and one dual function "alarm cancel" / "self test" button |
| Certifications & Standards | UL1778 (TUV), cUL (TUV), NOM, FCC Class B, FCC part 68 (US & Canada) |
| Recycled | No |
| Assembly Required | No |
| Country of Origin | China |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 2 year product warranty / $250,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only) |
| Manufacturer Info | |
|---|---|
| Brand | Tripp Lite by Eaton |
| Warranty Offered? | Yes |
| Manufacturer SKU | SMART1000LCD |
| Retail GTIN (UPC) | 00037332124999 |
| Country of Origin | CN |
| UNSPSC Number | 39121011 |
| Product ID | 9517715 |
